current location：Home>Products>Manual Positioners>Tilt Stages

TP207 multi-axis tilt platforms

    1.The stages provide two dimensional pitch and yaw adjustment.

    2.Axis for horizontal rotationdoes not change.

    3.Driven with fine thread screws.


  • description
  • parameters

TP207 multi-axis tilt platforms



1.The stages provide two dimensional pitch and yaw adjustment.

2.Axis for horizontal rotationdoes not change.

3.Driven with fine thread screws.




Related Products：

        COMBINATED STAGES



Model

TP207M

Table size （mm）

60×74

Tilt angle

±5o

Rotation angle

±2°

Driving

Micrometer head

Loading capacity (kg)

2.5

Weight （kg）

0.3
