TMS301 series multi-axis positioning stages
1.The stages allow for 5-axis adjustments.
2.High precision linear ball guides are
used.
3.Three translation axis movements are
driven by three individual micrometer heads.
4. Pitch and yaw adjustments are drivenwith
two M6X0.25 fine teeth screw rods.
5.Separate models are available for
right-hand and left-hand use.
- description
- parameters
|
Model |
TMS301 |
|
Travel （mm） |
Tx，Ty，Tz：13 |
|
Adjustment range |
θy，θz：±5° |
|
Minimum reading（mm） |
0.01 |
|
Resolution（mm） |
0.002 |
|
Loading capacity（kg） |
2.5 |
|
Weight（kg） |
1.15 |
