current location：Home>Products>Optics Mounts Series>Optics Mounts

GM100 series mirror mounts

    1. Two axis rotation orthogonal coplanar, so adjustment of the lens can be made by two dimensional orthogonal coplanarity

    2. M6×0.25 fine thread screw adjustment

    3. Imported spring reset

    4. Support of lens will be by three rigid PTFE

  • description
  • parameters

GM100 series mirror mounts




1. Two axis rotation orthogonal coplanar, so adjustment of the lens can be made by two dimensional orthogonal coplanarity

2. M6×0.25 fine thread screw adjustment

3. Imported spring reset

4. Support of lens will be by three rigid PTFE



Model

GM101

GM101B

GM102

GM103

GM104

ΦA Applied diameter（mm）

Φ50

Φ50.8

Φ80

Φ100

Φ102

ΦB

-

-

75

95

97

Adjusting rang of tilt

θy

±5°

θz

±5°

C

-

-

25

25

25

D

-

-

75

85

85

L

-

-

93

113

113

H

-

-

128.5

146.5

146.5

T

-

-

110

130

130

Weight（kg）

0.25

0.25

0.3

0.28

0.28
