current location：Home>Products>Optics Tables>Solid Breadboards

SB120 series solid breadboards

    1. Used high quality stainless steel

    2. M6 threaded holes array with distance 25mm in the surface for fixing device conveniently

    3. For special size and material can be customized

  • description
  • parameters

SB120 series solid breadboards




1. Used high quality stainless steel

2.M6 threaded holes array with distance 25mm in the surface for fixing device conveniently

3. For special size and material can be customized



1. Thickness : 6mm/8mm

2. Flatness:0.08mm/m2

3. Distance between holes:25mm

4. Diameter of holes:M6

5. Material:  high quality stainless steel



1. Thickness : 6mm/8mm

2. Flatness:0.08mm/m2

3. Distance between holes:25mm

4. Diameter of holes:M6

5. Material:  high quality stainless steel


Model

Table size（mm）

Table thickness（mm）

SB121

300×300×6

6

SB122

300×600×6

6

SB123

600×600×8

8
