TMS401 multi-axis positioning stage

1.The stages allow for 3-axis adjustments.

2. Actuated with dovetail slide guides.

3. Driven withfine teeth screw rods.

4. Resetspringeliminates return backlash.

5.TMS401 can be combined withVTS seriesstages to provide four-axisadjustment capability.
